• 1.5 hours

    Flight Endurance

  • 110 lbs

    Maximum Take-off Weight

  • 44 lbs

    Maximum Payload

KEY FEATURES

With the HT-50, pilots learn to navigate all aspects of HT-100 UAV operations, including:

  • Flight control systems identical to the HT-100.
  • Dual inter-meshing Flettner rotor system for enhanced stability and efficiency.
  • Advanced navigation and avionics systems, mirroring real-world mission environments.
  • Ground control station simulation, providing a realistic command experience.

By integrating the HT-50 into training programmes, operators reduce risks, improve efficiency, and enhance mission readiness—ensuring seamless adaptation to the HT-100 unmanned helicopter.

TECHNICAL DATA

Turbine 20 hp shaft turbine
Rotor Flettner double rotor system
Typical empty weight 143 lbs (65 kg)
Fuel types Jet A1 – other fuel types on demand (JP-8, JP-5)
Fuel consumption 2.4 gal/h
Data link type Fully encrypted MESH IP (SATCOM and LTE on demand)
Data link range Radio and antenna configuration up to 124 mi (depending on terrain topography and national regulations)
Operating temperature -13 °F to +131 °F (-25 °C to +55 °C)
Max. wind speed 25 kn/h (45 km/h)
Start and landing Fully autonomous

PERFORMANCE

Max. flight time 360 minutes
Max. airspeed 65 kn/h (120 km/h)
Max. flight mission/ payload weight 1 hrs / 112 lbs, 2 hrs / 94 lbs, 4 hrs / 60 lbs, 6 hrs / 30 lbs
Max. take-off weight 264 lbs (120 kg)
Max. payload and fuel 121 lbs (55 kg)
Operating ceiling (max. density altitude) 13,123 ft (4,000 m)
